Introducing the latest in portable solar technology.

Perception Lighting's Flexible Folding Solar Blanket Kits are lightweight, compact, and versatile making them the ultimate portable power solution.

Perception Solar Blankets are built tough to handle harsh Australian conditions and are designed for a quick and painless setup.

Simply unclip the straps, unfold and place in the sun!

The included charge controller ensures that your battery is charged with maximum efficiency and charging will automatically stop when the battery is full.

Solar mats can be used to maintain your battery when using Perception Lighting Camping Kits, 12-volt fridges, TVs, and other camping equipment.






COMPACT
DESIGN


 ARMOUR CELL
TECHNOLOGY


160 WATTS
8.1 AMPS


LIGHTWEIGHT
9 KG


10 YEARS OUTPUT
5 YEARS CANVAS





Design

The briefcase like design allows the panels to be folded to a compact size for easy storage while traveling and feature built-in legs to allow free-standing operation. This allows the panels to be positioned at different angles and allow airflow behind the panel for maximum efficiency. Placing your panels on your windscreen or bonnet this is not recommended due to both of these surfaces reaching high temperatures and prevent airflow from behind the panel. The panel is also equipped with eyelets on the corners and legs to allow the panel to be secured to the ground using pegs if required.





Dont get caught out by inferior products that force you to place them on HOT surfaces such as bonnets and windscreens which significantly decrease their efficiency from heat saturation.

Perception Lighting's Flexible Folding Solar Blankets come equipped with legs that allow free-standing operation that increase airflow, prevents heat saturation and allows the panel to be positioned away from your vehicle or camper.



Did you know? All solar panels are tested and rated at 25 degrees C and depending on how they are mounted, heat can reduce output efficiency by as much as 25%. As the temperature of the solar panel increases the output current decreases/ in effect reducing the solar panel’s production of power.

The back of the panel comes equipped with a built-in storage pouch to store the solar charge controller, extension cable and adapter leads. The bugs fold flat with the panel for storage and are secured with velcro.





Armour Cell Technology

Perception Lighting's MKII solar panels come equipped with the latest Armour Cell Technology. This heat, UV & impact resistant layer to provides the ultimate protection for solar cells.





Power Output & Weight

Our 160 Watt Solar panel produces up to whopping 8.1 Amps and weighs in at only 5.6 KG



Warranty



10 Years
Solar Cell Efficiency



5 Years
​Canvas



2 Years
​Cables & Regulator







Whats in the Kit?



Flexible Folding
Solar Blanket



10 Amp
PWM Regulator



5M Anderson
Extension Lead



Anderson Plug to
Aligator Clip Adapter







Charging

Perception Lighting's Solar panels are supplied with a PWM charge controller and fitted with Anderson Plugs to provide a plug & play solution that is quick and painless to setup. This also allows the supplied solar charge controller to be easily bypassed or if your setup is already fitted with a charge controller or battery management system. The use of standard 50A Anderson plug adds to the versatility and adaptability of the system so you won't have to source any proprietary or uncommon plugs in the future.







Technicial Specifications

Maximum Power (Watts): 160
Solar Cell Type: Monocrystalline
Max Power (Volts): 19.8V
Max Power (Amps): 8.1A
Open Circuit Voltage: 23.36V
Short Circuit Current: 8.89A
Operating Temperature: -20 to 50℃
Max System Voltage: 100V
Open Dimensions: 2110 x 530mm
Closed (Folded) Dimensions: 460 x 620mm
Closed (Folded) Thickness: 55mm
Weight 5.6KG
Solar Cell Warranty: 10 Years
Canvas Warranty 5 Years
Charge Controller & Cable Warranty: 2 Years

























SKU SOL160W-FS
Barcode # 702785125939
Brand Perception Lighting
Shipping Weight 11.0000kg
Shipping Width 0.580m
Shipping Height 0.100m
Shipping Length 0.580m
Shipping Cubic 0.033640000m3
Unit Of Measure ctn
