SRX Series 40.5" LED Single Row Light Bar






THE NEW STANDARD

Our all-new SRX SERIES LED light bars are the result of our proven experience in delivering high performance LED lighting. Fitted with 40 of OSRAM’s® finest DURIS® LEDs and a combination spot/flood reflector the SRX series produces a remarkable beam that pushes the flood beam out at 50° and spot beam at 5° all the way to whopping 1 lux @ 690m

The SRX range feature our all-new TruOptics beam pattern to focus the light where you need it most, resulting in a +65% increase in lux performance in comparison to the outgoing 10 Series LED bars.



INSTANT PERFORMANCE

  • The SRX-40 features 40 of OSRAM’s® finest DURIS® LEDs, selected for its high output and matched optical geometry

  • The combination spot and flood reflector forms an astonishing beam that throwing beam wideout at 50° and spot beam punching all the way down to whopping 1 lux @ 690m

  • Pure White 5700K Colour temperature offers stunning clarity and definition and optimal Colour Rendering Index (CRI).

  • New circuit design allows 97% of input power to go directly to LEDs.


BUILT RUGGED

  • Diecast aluminum faceplate, extruded Aluminum heat sink

  • Dupont Powdercoat is UV and abrasion-resistant to ensure that our bars will never discolor.

  • Gore® Military breather protects against water & dust ingress

  • LEXAN Lens is unbreakable and optically clear

  • IP69K  - Dust & high-pressure water-proof. No hassle car washing!



VERSATILE MOUNTING

  • End mounts allow for 360 degrees of rotation.


CONTENTS

1 X 40.5” SRX Series Lightbar
2 x Side mount legs
1 x Male & female deutcsh connectors



OSRAM LED TECHNOLOGY

Perception SRX series lightbars utilize a 5-watt OSRAM Duris P8 LEDs.
The result is amazing distance and flood performance. These high output
5 watt LEDs are not to be confused with competitors inferior 3-watt counterparts.



THE PERCEPTION LIGHTING® GUARANTEE

All Perception Lighting products are manufactured using the highest quality materials. We are so confident that we stand behind this product with a comprehensive 5 Year Australian Warranty.





SPECIFICATIONS:

Lux   1 Lux @ 690M
LED Technology      40 x OSRAM DURIS
Lumens   24,320
Power Consumption   9.1A @ 13.V
IP Rating   IP69K
Beam Pattern   Driving Beam (Combination)
Operating Voltage   10-30VDC
Colour Temperature   5700K
Weight   2.5KG
Body Material   Diecast Aluminium
Lens Material   GE Lexan Polycarbonate
Bracket   Steel
Bracket Adjustability   360 Degree
Lifespan   50,000+ Hours
