DETAILS


Introducing Perception Lighting's entry-level LED Driving Lights

KEY FEATURES
Adjustable bottom mount for versatility
Oversized heatsink ensures the LEDs run cooler
IP68 Rating ensures the lights are 100% waterproof
Long lifespan: LEDs have a 50,000 + Hrs lifespan
Unbreakable lens: polycarbonate lens is unbreakable

WHAT’S INCLUDED
2 x 7”  Adventure Series LED Driving Lights
▶ 2 X Clear protective covers
2 x Brackets
2 x Male Deutsch plugs
▶  Nuts & bolts for mounting

SPECIFICATIONS

LED POWER 160W (32 x 5W)
LUX (PAIR) 1 LUX @ 468m
BEAM DISTANCE  0.25 LUX @ 936m
WATERPROOF RATING IP68
CURRENT DRAW 5.8A @ 12V
BEAM PATTERN Driving Beam
OUTPUT (PER LIGHT) 9,600 Lumens
HOUSING MATERIAL Aluminum
LENS MATERIAL Polycarbonate
MOUNTING BRACKET Bottom
OPERATING VOLTAGE 11-32V DC
COLOUR TEMPERATURE 6000K
LED LIFESPAN 50,000+ hours



LUX DIAGRAM

All our products are manufactured using the highest quality materials.  We are so confident that we stand behind this product with a comprehensive 2 Year Australian Warranty.

 KEY FEATURES- Adjustable side mounts for versatility
- Oversized heatsink ensured LEDs run cooler and brighter
- IP68 Rating ensures 100% waterproofness
- Long lifespan: OSRAM LEDs have a 50,000 + Hrs lifespan
- Unbreakable Lens: Polycarbonate Lens is unbreakable
- Latest reflector technology achieves 97% efficiency

The DRF series lightbars utilize a 3-watt OSRAM LEDs. The result is impressive distance and flood performance.

Iso Lux Diagram:

Contents:

1 x 22" DRF Series Lightbar

2 x side mount legs

1 x Male and Female deutch connectors

Specificaions

LED POWER 120W (40 x 3W)
LED MANUFACTURER Genuine OSRAM®
LUX (PAIR) 1 LUX @ 350m
BEAM DISTANCE  0.25 LUX @ 700m
WATERPROOF RATING IP68
CURRENT DRAW 6.6A @13.2V
BEAM PATTERN Combination Spot & Flood
OUTPUT 8,400 Lumens
HOUSING MATERIAL Diecast Aluminium
LENS MATERIAL Polycarbonate
MOUNTING BRACKET Side
OPERATING VOLTAGE 10-30V DC
COLOUR TEMPERATURE 6,000K
LED LIFESPAN 50,000 hours
CERTIFICATIONS CE, RoHS, C-Tick
